Gin Osprey

 It was conceived to meet the demands of professional tandem pilots, but its accessible characteristics mean that it appeals equally to leisure pilots.

Easy to manage on take-off and landing

With a surface area of only 34m2, the Osprey is easy to manage on take-off. Compared to a conventionally sized tandem, a greater margin of safety is possible in stronger winds. Despite the reduced area, landing remains comfortable, even in nil wind. The EPT (Equalised Pressure Technology) airfoil enables a low stall speed with good energy retention and a well-defined flare window.

Speed and stability

The Osprey has a wide speed range and a high maximum speed. The 11cm trimmer is uniquely long and the wing remains stable at even the highest speeds. In addition, a 2cm negative trim allows the pilot to set a lower trim speed. The glider is certified EN B across the entire weight range of 100-210kg.

A versatile all-rounder

The Osprey fills the gaps left by other tandems on the market. The unique design reduces the number of lines and the three riser levels make sorting of the lines straightforward. It’s also well suited for soaring in stronger winds, and its direct and responsive handling makes thermal flying a pure joy.

Technical details

- +11cm / -2cm trimmer

- Equalized Pressure Technology (EPT)

- "S-inlets" for better inflation

- 3 risers / 3 lines spanwise

- Split A risers for easy big ears

- cleat on C-riser to fix A3-line in the big ear position

- Colour-coded lines for easy identification

- Strong and durable materials

- Trailing edge mini-ribs

- three different tandem spreaders available: light, supple (soft) and rigid (hard)

- also certified as a solo wing

Materials

Canopy cloth

Top surface: Dominico 30D (water repellent) 41g/m2

Lower surface: Dominico 30D (water repellent) 41g/m2

Lines

Upper: Liros DSL 70 / PPSL 120 / GIN TGL 80

Middle: Liros DSL 70 / PPSL 120 / 200

Main: Edelrid 7343-280 | 420 | Gin Gliders TGL 400
